Console - Electric UI

A Console allows for persistent logs of rich text to be displayed.

Screenshot of component Console overview

Usage

Consoles use the Data Source system, and accept a dataSource prop. This allows for persistent storage of logs when navigating through the application.

import { Console } from '@electricui/components-desktop-blueprint-timeseries'
import { useMessageDataSource } from '@electricui/core-timeseries'

const OverviewPage = () => {
  const textDataSource = useMessageDataSource<string>('text')

  return <Console dataSource={textDataSource} />
}

While text can be passed through directly, usually a simpler data type will be used in the Event which can be expanded to text via the component's accessor.

Screenshot of component Console transformed-text

const counterDataSource = useMessageDataSource<number>('counter')

const OverviewPage = () => {
  return (
    <Console
      dataSource={counterDataSource}
      accessor={num => `The hardware counted to ${num}!`}
    />
  )
}

Complex objects

Complex objects can be logged inline, in additional other log methods being used.

By passing an object of the form { method: "log", args: ["Simply log", num] }, each argument will be rendered with the default inspector view for its type.

Screenshot of component Console other-methods

const OverviewPage = () => {
  const counterDataSource = useMessageDataSource<number>('counter')

  return (
    <Console
      dataSource={counterDataSource}
      accessor={(num: number) => {
        switch (num) {
          case 0:
            return { method: `warn`, args: [`Warn the user about`, num] }
          case 1:
            return { method: `error`, args: [`Error about...`, num] }
          case 2:
            return { method: `debug`, args: [`Debug log about...`, num] }
          default:
            return { method: `log`, args: [`Simply log`, num] }
        }
      }}
    />
  )
}

Ordering

The display ordering can be changed via the orderBy and order props.

Note that changing the ordering causes a re-fetch from the persistence engine.

Make sure to memoise the ordering function before passing it to the Console component, otherwise a new instance will be produced each render, resulting in degraded performance.

import {
  Console,
  ConsoleRefAPI,
} from '@electricui/components-desktop-blueprint-timeseries'
import { useMessageDataSource, Time } from '@electricui/core-timeseries'
import { useState, useCallback, useMemo } from 'react'
import { Button as BlueprintButton } from '@blueprintjs/core'
import { IconNames } from '@blueprintjs/icons'

const OverviewPage = () => {
  const counterDataSource = useMessageDataSource<number>('counter')

  const [order, setOrder] = useState(1)

  const onClick = useCallback(() => setOrder(state => state * -1), [setOrder])

  const ordering = useMemo(() => {
    if (order === 1) {
      return (a: Time, b: Time) => a - b
    } else {
      return (a: Time, b: Time) => b - a
    }
  }, [order])

  return (
    <>
      <div style={{ display: 'flex', justifyContent: 'end', padding: 5 }}>
        <BlueprintButton
          onClick={onClick}
          icon={
            order === 1
              ? IconNames.SORT_NUMERICAL
              : IconNames.SORT_NUMERICAL_DESC
          }
        >
          {order === 1
            ? 'Ordered By Ascending Time'
            : 'Ordered By Descending Time'}
        </BlueprintButton>
      </div>
      <Console
        order={ordering}
        dataSource={counterDataSource}
        accessor={(data, time) => `Message received at time: ${time}`}
      />
    </>
  )
}

Clearing

The internal store of data can be cleared via an imperative ref handle. Any re-fetching (via a component re-render, or an ordering change for example) may cause the data to re-appear. This feature is intended for 'quick development interfaces'.

Screenshot of component Console clear-button

import {
  Console,
  ConsoleRefAPI,
} from '@electricui/components-desktop-blueprint-timeseries'
import { useMessageDataSource } from '@electricui/core-timeseries'
import { useRef, useCallback } from 'react'
import { Button as BlueprintButton } from '@blueprintjs/core'

const OverviewPage = () => {
  const counterDataSource = useMessageDataSource<number>('counter')

  const consoleRef = useRef<ConsoleRefAPI>(null)

  const onClear = useCallback(() => consoleRef.current?.clear(), [])

  return (
    <>
      <div style={{ display: 'flex', justifyContent: 'end', padding: 5 }}>
        <BlueprintButton onClick={onClear}>Clear</BlueprintButton>
      </div>
      <Console
        ref={consoleRef}
        dataSource={counterDataSource}
        accessor={(num: number) => {
          switch (num) {
            case 0:
              return { method: `warn`, args: [`Warn the user about`, num] }
            case 1:
              return { method: `error`, args: [`Error about...`, num] }
            case 2:
              return { method: `debug`, args: [`Debug log about...`, num] }
            default:
              return { method: `log`, args: [`Simply log`, num] }
          }
        }}
      />
    </>
  )
}
